N6L08L-WF

Model:N6L08L-WF Features:8CH 3MP/4CH 5MP WiFi video inputStorage management: support local TF card up to 128G, automatic loop coverage after full storage8CH 3MP video input, 1CH audio output, No alarm

Model:

N6L08L-WF



Features:

8CH 3MP/4CH 5MP WiFi video input

Storage management: support local TF card up to 128G, automatic loop coverage after full storage

8CH 3MP video input, 1CH audio output, No alarm, No RS485

Support VGA and HDMI simultaneously output

Support 1pcs of HDD, Max. 10TB

Support Onvif, access third party

Support cloud storage

1*RJ45 1*10/100/1000Mbps ethernet port

Support remote access, mobile monitoring (iOS, Android), App: XMeye Pro and iCSee

Support “SYNC”Wireless coding(Press the Reset button to perform SYNC wireless code matching)

Support AI humanoid detection and face detection



Specification:

Model

N6L08L-WF

System

Main processor

Hi3536E

Operating system

Embedded LINUX operating system

System resource

Multi-channel real-time recording synchronously,   multi-channel real-time playback, multi-channel multi-user network operation,   USB back up.

Interface

Operation interface

16bit real color GUI interface support mouse operation

Display screen

1/4/8/9/16 screen

Video

Video Input

8*3M/4*5M

Video Compression

H.265AI/H.265+ (compatible with H.265/H.264)

Monitor quality

VGA (1080P at most); HDMI (4K at   most)

Preview ability

8*3MP; 4*5MP

Encode capability

8*3MP; 4*5MP

Decode capability

8*3MP; 4*5MP

Humanoid   / Face Detection

Support (Depend on camera)

Motion detection

192(16×12) detection areas, multiple sensitivity

Audio

Audio compression

G711A

Bidirectional talk

support

Record and playback

Record mode

manual>alarm>motion detection>timing

Local playback

1~8ch playback synchronously

Video search

Time, date, event, channel search

Record Storage

HDD, Network, Cloud

Backup Mode

Network backup, USB hard disk, USB burner, SATA burner

Interface

Video output

1ch VGA, 1ch HDMI

Loop output

No

Audio input

1ch RCA(200-2800mV,30KΩ)

Audio input

1ch RCA(200-3000mV,5KΩ)

Alarm input

N/A

Alarm output

N/A

Network port

1*RJ45 10M/100M Adaptive Ethernet port+ 4/8ch WIFI

PTZ control

No

USB port

2*USB2.0

HDD port

1 SATA ports (each max to 14T)

Wireless port

Not support 3G

Other

Power

12V/2A

Consumption

<10W (not including HDD)

Temperature

0° C~ +55° C~

 Humidity

10%90%

Atmosphere pressure

86kpa106kpa

Dimension

L255*W230*H45MM

Weight

1.9kg



This specification is subject to change without notice.
